Brand new 17" LCD monitor specifically designed for arcade, amusement, table top games, ...
Part number: 49-2603-30
NOTE: This is the NON-touch screen version and these models do NOT have HDMI inputs
CGA, VGA, SVGA or XGA resolutionsWorks in most Amusement applicationsReplaces outdated CRT monitors - new modern lookHigh-grade components including SAMSUNG LED panels. Better picture quality, balanced picture image and a longer life span with no burn-in (which is typical with traditional CRT monitors)Suzo-Happ GEN III frame design which allows you to mount the LCD mounting brackets in various positions around the LCD (left to right or top to bottom). Universal mounting capabilitiesUnique frame design that allows you to adjust the depth of the LED panel up to 0.25 inchesPre-programmed for automatically sync with popular CGA games
17” Specifications: Power Supply: +12 VDC 2.5A MAX. Input Video Signal: Signal : RED, GREEN, BLUE Analog only. Polarity : Positive. Level : Analog from 0.714 to 2.5 [VP-P]. Maximum Dot Clock : 135[MHz]. Input Sync Signal: Polarity : (+) or (-) H,V Separate or Composite sync. Level : TTL Compatible. High : 2.4 ~ 5.0[V]. Low : 0.0 ~ 0.8[V]. Scan Frequency : 15 ~ 80.0[KHz]
DB15 to 10 pin adapter board supplied. Center Positive Coaxial Power Jack. Screen comes with a power supply with US Line cord, 1.5M VGA cable, DB15 to CGA 10 pin adapter board.FREE SHIPPING to lower 48 states.Please note: If item is returned, $25 will be deducted from return amount to cover outbound shipping cost
